- Daily Program
- Slim Format 17.5 mm
- Captive Setting keys
- Manual Override Switch “Permanent OFF / Automatic / Permanent ON”
- Simple to Install
- Easy to Read Switching Program
- Make / Brand: Hugo Muller
- Country of Origin: Germany
- Technical Data
|Supply voltages||230 V, 50-60 Hz|
|Power consumption (real power)||0,4 W|
|Switch (potential-free)||Normally open, gap < 3mm (µ)|
|Manual override switch||Permanent ON / Permanent OFF / AUTO|
|16 A / 250 V~ at cosφ=1
2,5 A / 250 V~ at cosφ=0,6
|Min. switching power||1.000 mW (10 V / 10 mA)|
|Filament Lamp, Halogen Lamp||2.000 W|
|Fluorescent Lamp uncopensated||1.000 W|
|Fluoresent Lamp series compensated||750 W|
|LED (230 V~) / CFL||200 W|
|Minimum switching interval||15 Min.|
|Accuracy (at 23°C)||≤±1 Sec./day|
|Power back-up (at 20°C)||approx. 100 h.|
|Permitted ambient temperature||–5°…+50°C|
|Dimensions||45 x 17,5 x 58 mm|
|Mounting||35 mm DIN-rail|
|Type of connection||Screw terminals|
|Type of protection||IP 20 to DIN EN 60529|
|Class of protection||II when installed according to regulations|
|Mode of operation
(DIN EN 60730-1)
(DIN EN 60730-2-7)
|Degree of contamination
(DIN EN 60730-1)
|Rated surge voltage
(DIN EN 60730-1)
